Description:

Features:

• 4-blade, 46" trowel
• Briggs & Stratton XR 1450 engine with 9.0 HP
• Minimum 60-130 Maximum RPM blade speed
• Optional SXH Standard Handle included
• 46-inch (1170mm) guard ring diameter
• 1-year limited warranty for the trowel, 2-year commercial warranty for the engine
• Front access panel for quick access to trowel arms and blades
• Includes a center mount lifting bale
• Simplified routine maintenance with spider and thrust collar assembly design
• The gearbox features top-quality components and a large oil capacity for trouble-free performance over the years
• Optimally balanced for smooth finishing
• Handles available with either Quick Pitch or Standard (knob type) pitch control

Specifications:

General Information

• Clutch Type: Centrifugal
• Number of Blades: 4
• Ring Diameter: 46 in (1,168.4 mm)
• Rotor Speed: 60-130 RPM

Handle Options

• SXH
• QXH

Dimensions & Weights

• Overall Length: 75 in (1,910 mm)
• Overall Width: 46 in (1,170 mm)
• Overall Height: 41 in (1,044 mm)
• Operating Weight: 277 lb (125.6 kg)
• Shipping Weight: 285 lb (129.2 kg)
